Description
MADE FOR PROFESSIONAL FARMERS AND CONTRACTORS.
The new 8280 TTV is a reliable, powerful and fully connected working machine with the perfect technology mix for professional farmers and contractors.
Equipped with the latest digital solutions from DEUTZ-FAHR, the new 8280 TTV enables you to operate the tractor in the most efficient way and thus, to save time and money. With its powerful twin turbo engine with 287 HP and a max speed of 60kp/h, DualSpeed Front PTO and Dry Front Disc brakes it works fast and is extremely agile on and off the field. Thanks to the fully adjustable, intelligent front axle suspension and the further developed MaxiVision Cab, the new 8280 TTV maintains a comfortable working environment – even on the most demanding jobs.
DRIVEN BY EFFICIENCY.
The 8280 TTV is equipped with an all-new DEUTZ 6-cylinder engine with 6,1 liters capacity and double turbocharger. It is designed for the maximum in performance and efficiency. The state-of-the-art common rail system meets the requirements of the EU Stage V and the injection pump is lubricated by oil – working with a high injection pressure of 2,000 bar that optimizes th
e combustion of fuel and AdBlue and guarantees a reactive and dynamic engine behaviour. Thus, the well-rounded torque curve ensures high power reserves at lower engine speeds.
DYNAMIC DRIVING.
The new continuously variable transmission SDF7780 is the result of many years experience in transmission development and production. Due to the intelligent combination of a stepped planetary gearbox, clutch unit and two hydrostatic units, it evolves a new compound transmission, combining the benefits from each element and guaranteeing an absolute optimum of power flow.
The 8280 TTV impresses with powerful acceleration, smooth deceleration and a fast response to changes in load. A simple transmission structure with two automatically shifted drive ratios allows smooth and automatic changes from lower to higher speeds, without any noise.
THE POWER OF FLEXIBILITY.
The new 8280 TTV provides complete flexibility with a choice of 3 PTO speeds as standard: 540ECO/1000/1000ECO. In combination with the Dualspeed Front PTO, wider and more efficient applications can be used. The implement loading on the rear PTO shaft is automatically measured in a fraction of a second and the engagement of the PTO clutch is proportional to the actual load. The modulated start up can be adjusted in the iMonitor 3.
The ECO PTO saves up to 18% of fuel consumption and the proportional PTO offers driveline protection for both the tractor and implement.
The complete PTO unit can be removed for any maintenance without major dismantling of the tractor.
RISING THE PRODUCTIVITY.
With a maximum lifting capacity of the rear linkage of up to 11,100 kg, the 8280 TTV tractor has the power to lift a wide range of implements. To guarantee the maximum versatility of the hydraulics, the new 8280 TTV is available in different configurations, all with electronic valves with full proportional controls.
There are up to five hydraulic control valves on the rear side, while the front area is equipped with up to three. The highlight: all valves can be controlled proportionally. The operation of the 8th spool valve is located on the small joystick and can be precisely used for combined maneuvers with the cross lever.
SAFETY AND PRECISION ARE ALWAYS ON.
Productivity requires a maximum of vehicle control. In the field and on the street. At top speed as well as in difficult ground conditions and with the heaviest implement. The suspension concept of the front axle and the brake system of the 8280 TTV is unique in this tractor class.
The intelligent and adaptive suspension system give the tractor maximum stability – for heavy towing and for pushing tasks. The innovative anti-dive system stabilizes the tractor during all transport tasks and increases safety. The front axle suspension can be activated or deactivated independently from the speed – indispensable for heavy pulling applications or mowing.
DESIGNED FOR LONG LASTING COMFORT.
The new 8280 TTV is a working machine with a great level of comfort even on demanding jobs. Pneumatic cab suspension, computerized analysis of airflows, the use of high-quality materials and the spaciousness of the cab of the new 8280 TTV create an inviting, comfortable and productive working environment.
The ergonomic design of the controls, the logical layout and the clearly presented information make driving the tractor that much easier and safer. The cab is detached from the new designed bonnet, which keeps the heat, vibrations and noise out of the cab and raises the driver’s comfort on a new high-class level.
